BARDOLINO FLAT

  • high quality aluminium profile
  • flexibly useable as surface-mounted or ground profile
  • the flat build-design enables easy integration in compact spaces
  • in combination with an opal white cover and compatible LEDlight flex, a homogenous light distribution can be achieved
  • RAL powder coating on request





ANr*DescriptionDimensionsHousing/
colour
Datasheets
62399201 aluminium anodized1000×18,4×13 mm (l×w×h)natural tone
62399202 aluminium anodized2010×18,4×13 mm (l×w×h)natural tone
62399203 aluminium anodized3020×18,4×13 mm (l×w×h)natural tone
62399205 aluminium anodized5030×18,4×13 mm (l×w×h)natural tone
62399201_9010 aluminium powder coated1000×18,4×13 mm (l×w×h)white RAL9010
62399202_9010 aluminium powder coated2010×18,4×13 mm (l×w×h)white RAL9010
62399203_9010 aluminium powder coated3020×18,4×13 mm (l×w×h)white RAL9010
62399205_9010 aluminium powder coated5030×18,4×13 mm (l×w×h)white RAL9010
62399201_9005 aluminium powder coated1000×18,4×13 mm (l×w×h)black RAL9005
62399202_9005 aluminium powder coated2010×18,4×13 mm (l×w×h)black RAL9005
62399203_9005 aluminium powder coated3020×18,4×13 mm (l×w×h)black RAL9005
62399205_9005 aluminium powder coated5030×18,4×13 mm (l×w×h)black RAL9005
62399201, 62399202, 62399203, 62399205: Please consider linear extension with temperature variations
ANrDescriptionDimensionsHousing/
colour
Datasheets
62399301 BARdolino, Diffuser opal, for a homogenous and glare-free light distribution1000×14,8×8 mm (l×w×h)transparent opal white
62399302 BARdolino, Diffuser opal, for a homogenous and glare-free light distribution2010×14,8×8 mm (l×w×h)transparent opal white
62399303 BARdolino, Diffuser opal, for a homogenous and glare-free light distribution3020×14,8×8 mm (l×w×h)transparent opal white
62399305 BARdolino, Diffuser opal, for a homogenous and glare-free light distribution5030×14,8×8 mm (l×w×h)transparent opal white
62399371 BARdolino, Diffuser satined, for a diffused light distribution and concealment of the technology1000×14,8×8 mm (l×w×h)transparent satined
62399372 BARdolino, Diffuser satined, for a diffused light distribution and concealment of the technology2010×14,8×8 mm (l×w×h)transparent satined
62399373 BARdolino, Diffuser satined, for a diffused light distribution and concealment of the technology3020×14,8×8 mm (l×w×h)transparent satined
62399375 BARdolino, Diffuser satined, for a diffused light distribution and concealment of the technology5030×14,8×8 mm (l×w×h)transparent satined
62399401 BARdolino, Diffuser clear, for max. light yield and protection of the LED strip1000×14,8×8 mm (l×w×h)transparent clear
62399402 BARdolino, Diffuser clear, for max. light yield and protection of the LED strip2010×14,8×8 mm (l×w×h)transparent clear
62399403 BARdolino, Diffuser clear, for max. light yield and protection of the LED strip3020×14,8×8 mm (l×w×h)transparent clear
62399405 BARdolino, Diffuser clear, for max. light yield and protection of the LED strip5030×14,8×8 mm (l×w×h)transparent clear
62399311 BARdolino, Diffuser opal, walkable up to 500 kg, break-proof/impact resistant1000×14,8×8 mm (l×w×h)transparent opal white
62399312 BARdolino, Diffuser opal, walkable up to 500 kg, break-proof/impact resistant2010×14,8×8 mm (l×w×h)transparent opal white
62399313 BARdolino, Diffuser opal, walkable up to 500 kg, break-proof/impact resistant3020×14,8×8 mm (l×w×h)transparent opal white
62399315 BARdolino, Diffuser opal, walkable up to 500 kg, break-proof/impact resistant5030×14,8×8 mm (l×w×h)transparent opal white
62379151 BARdolino, Diffuser satined, PMMA, 15° lens for a directed light focus1000×14,8×8 mm (l×w×h)transparent satined
62379152 BARdolino, Diffuser satined, PMMA, 15° lens for a directed light focus2010×14,8×8 mm (l×w×h)transparent satined
62379153 BARdolino, Diffuser satined, PMMA, 15° lens for a directed light focus3020×14,8×8 mm (l×w×h)transparent satined
62379155 BARdolino, Diffuser satined, PMMA, 15° lens for a directed light focus5030×14,8×8 mm (l×w×h)transparent satined
62379301 BARdolino, Diffuser satined, 30° lens for a directed light focus1000×14,8×8 mm (l×w×h)transparent satined
62379302 BARdolino, Diffuser satined, 30° lens for a directed light focus2010×14,8×8 mm (l×w×h)transparent satined
62379303 BARdolino, Diffuser satined, 30° lens for a directed light focus3020×14,8×8 mm (l×w×h)transparent satined
62379305 BARdolino, Diffuser satined, 30° lens for a directed light focus5030×14,8×8 mm (l×w×h)transparent satined
62379601 BARdolino, Diffuser satined, 60° lens for a directed light focus1000×14,8×8 mm (l×w×h)transparent satined
62379602 BARdolino, Diffuser satined, 60° lens for a directed light focus2010×14,8×8 mm (l×w×h)transparent satined
62379603 BARdolino, Diffuser satined, 60° lens for a directed light focus3020×14,8×8 mm (l×w×h)transparent satined
62379605 BARdolino, Diffuser satined, 60° lens for a directed light focus5030×14,8×8 mm (l×w×h)transparent satined
62399361 BARdolino, Diffuser high, opal, 180°, for an allround homogenous light distribution1000×18,4×17,8 mm (l×w×h)transparent opal white
62399362 BARdolino, Diffuser high, opal, 180°, for an allround homogenous light distribution2010×18,4×17,8 mm (l×w×h)transparent opal white
62399363 BARdolino, Diffuser high, opal, 180°, for an allround homogenous light distribution3020×18,4×17,8 mm (l×w×h)transparent opal white
62399365 BARdolino, Diffuser high, opal, 180°, for an allround homogenous light distribution5030×18,4×17,8 mm (l×w×h)transparent opal white
62399391 BARdolino, Diffuser semi-circular, opal, for all-round homogenous light distribution1000×18,4×14,4 mm (l×w×h)transparent opal white
62399392 BARdolino, Diffuser semi-circular, opal, for all-round homogenous light distribution2000×18,4×14,4 mm (l×w×h)transparent opal white
62399393 BARdolino, Diffuser semi-circular, opal, for all-round homogenous light distribution3000×18,4×14,4 mm (l×w×h)transparent opal white
62399395 BARdolino, Diffuser semi-circular, opal, for all-round homogenous light distribution5000×18,4×14,4 mm (l×w×h)transparent opal white
62399301, 62399302, 62399303, 62399305, 62399371, 62399372, 62399373, 62399375, 62399401, 62399402, 62399403, 62399405, 62399311, 62399312, 62399313, 62399315, 62399361, 62399362, 62399363, 62399365: Please consider linear extension with temperature variations
ANrDescriptionMounting
type
Housing/
colour
Datasheets
62398614_9005 Profile End Caps, aluminium powder coatedschraubbarblack RAL9005
62398614_9010 Profile End Caps, aluminium powder coatedschraubbarwhite RAL9010
62399396 Profile End Caps, 2x BARdolino end cap flat semicircular, suitable for cover 6239939x, incl. 4 screwsschraubbarAluminium
62399609 Profile End Caps, 1x BARdolino BARdolino end cap flat with 90° wall clip, aluminiumschraubbarAluminium
62399604 Profile End Caps, 2x BARdolino end cap flat, grey plastic, incl. 4 screwsschraubbarsilbergrau
62399369 Profile End Caps, 2x BARdolino end caps frosted for plastic cover high 180°schraubbartransparent opal
62398605 Profile End Caps, 1x BARdolino end cap flat, with drill hole M8x1 thread for cable (Ø 3.5 - 5.5mm), incl. 2 screwsschraubbarAluminium
62398614 Profile End Caps, 2x BARdolino end cap flat, aluminium, incl. 4 screws, thickness: 3mmschraubbarnatural tone
50990190 Profile brackets, Bardolino mounting clip set, incl. 2 holding clips + 2 screws, high holding forceHalteklammernEdelstahl
50990090 Profile brackets, 2x mounting clips, incl. screws, suitable for profiles of the BARdolino familyschraubbarEdelstahl
50990291 Profile brackets, 1x metal connector, suitable for profiles of the BARdolino familyschraubbarchrom
50990191 Profile brackets, 2x mounting clips pivoted, incl. screws, suitable for profiles of the BARdolino familyHalteklammernEdelstahl
50990091 Profile brackets, 2x mounting clips 45°, incl. screws, suitable for profiles of the BARdolino familyHalteklammernEdelstahl

BARdolino flat: One Profile. Abundant Possibilities.

Light effect

Diagrams: BARdolino flat with opal white diffuser and LEDlight flex 08 8 HIGH EFFICIENCY 2.0

Front view

Side view

BARdolino flat with opal white diffuser

BARdolino flat with semi-circular diffuser, opal white

BARdolino flat with opal white 180° diffuser

BARdolino flat with satined diffuser

BARdolino flat with 15° lens diffuser, satined

BARdolino flat with 30° lens diffuser, satined

BARdolino flat with 60° lens diffuser, satined

BARdolino flat with clear diffuser
