PINO HP

  • high quality aluminium profile, anodised
  • flexibly useable as surface-mounted or luminaire profile
  • round design-build
  • with integrated cooling body for LED strips with higher
  • lumen and power output
  • with half-round cover for a broad light distribution
  • universal mounting via rear-side nut, suitable for M3 nuts
  • in combination with an opal white cover and compatible LEDlight flex, a homogenous light distribution can be achieved


  • aluminium anodized
  • Housing/colour: Aluminium



ANr*DimensionsDatasheets
62399431 1000×20,8×13,2×Ø20,8 mm (l×w×h×d)
62399432 2010×20,8×13,2×Ø20,8 mm (l×w×h×d)
62399433 3020×20,8×13,2×Ø20,8 mm (l×w×h×d)
62399435 5030×20,8×13,2×Ø20,8 mm (l×w×h×d)
Please consider linear extension with temperature variations
ANrDescriptionDimensionsHousing/
colour
Datasheets
62389961 GARgano, Diffuser clear, 30° lens for a directed light focus1000×20×10 mm (l×w×h)transparent
62389962 GARgano, Diffuser clear, 30° lens for a directed light focus2010×20×10 mm (l×w×h)transparent
62389963 GARgano, Diffuser clear, 30° lens for a directed light focus3020×20×10 mm (l×w×h)transparent
62389965 GARgano, Diffuser clear, 30° lens for a directed light focus5030×20×10 mm (l×w×h)transparent
62396901 GARgano, Diffuser semi-circular, satined, for a diffused light distribution and concealment of the technology1000×20×10 mm (l×w×h)transparent satined
62396902 GARgano, Diffuser semi-circular, satined, for a diffused light distribution and concealment of the technology2010×20×10 mm (l×w×h)transparent satined
62396903 GARgano, Diffuser semi-circular, satined, for a diffused light distribution and concealment of the technology3020×20×10 mm (l×w×h)transparent satined
62396905 GARgano, Diffuser semi-circular, satined, for a diffused light distribution and concealment of the technology5030×20×10 mm (l×w×h)transparent satined
62397901 GARgano, Diffuser semi-cirualar, opal, for a homogenous and glare-free light distribution1000×20×10 mm (l×w×h)transparent opal white
62397902 GARgano, Diffuser semi-cirualar, opal, for a homogenous and glare-free light distribution2010×20×10 mm (l×w×h)transparent opal white
62397903 GARgano, Diffuser semi-cirualar, opal, for a homogenous and glare-free light distribution3020×20×10 mm (l×w×h)transparent opal white
62397905 GARgano, Diffuser semi-cirualar, opal, for a homogenous and glare-free light distribution5030×20×10 mm (l×w×h)transparent opal white
62398901 GARgano, Diffuser semi circular, clear, for maximum light yield and protection of the LED strip1000×20×10 mm (l×w×h)transparent clear
62398902 GARgano, Diffuser semi circular, clear, for maximum light yield and protection of the LED strip2010×20×10 mm (l×w×h)transparent clear
62398903 GARgano, Diffuser semi circular, clear, for maximum light yield and protection of the LED strip3020×20×10 mm (l×w×h)transparent clear
62398905 GARgano, Diffuser semi circular, clear, for maximum light yield and protection of the LED strip5030×20×10 mm (l×w×h)transparent clear
Please consider linear extension with temperature variations
ANrDescriptionMounting
type
Housing/
colour
Datasheets
50990191 Profile brackets, 2x mounting clips pivoted, incl. screws, suitable for profiles of the BARdolino familyHalteklammernEdelstahl
62399437 Profile brackets, 2x mounting clips, 2 screws, suitable for profiles of the Pino familyschraubbarchrom
62399438 Profile brackets, mounting clip, profile groove incl. mounting accessories, for mounting bracket and cantilever, suitable for Pino HPschwenkbarEdelstahl
62399448 Profile End Caps, 2x Pino end caps, aluminium, incl. screwsschraubbarAluminium
62399487 BERgamo HP mounting bracket and cantilever arm, mounting bracket standard, for mounting in ceiling and floor, incl. 2 screws and 2 dowels, distance to wall 15 mm
62399488 BERgamo HP mounting bracket and cantilever arm, cantilever arm, for mounting on walls, incl. 2 screws and 2 dowels, distance to wall 65 mm
62399489 BERgamo HP mounting bracket and cantilever arm, cantilever arm long, for mounting on walls, incl. 2 screws and 2 dowels, distance to wall 201 mm
65300160 Profile brackets, suspension for ceiling installation (2x 150cm wire cable Ø 1mm with M3 thread, 2x suspension brackets) incl. screw nutsAbhängeseilsilver
