Now available: LED Solutions 2021

LED Solutions For expressive lighting projects

Discover innovations and further developments of our product range with the highest quality standards on almost 400 pages in the new LED Solutions catalogue 2021 now.

Banner LED Solutions 2021

High-quality pendant luminaire with UGR < 16

Innovative optics with high-quality design: the new 230 V MILANO UGR < 16 pendant luminaire in black powder-coated aluminium does not create glare and creates a harmonious light pattern. It is ideal for monitor workstations and, with a luminous flux of up to 3,000 lm/m, can also be used for general lighting, for example in retail outlets. It is dimmable via an integrated DALI power supply unit from Tridonic which simplifies the installation. The luminaire is available in 4000 K as standard with further color temperatures available on request. A second version with Tunable White light source means that color temperatures can be continuously adjusted from 2700 - 6500 Kelvin, which means that the MILANO UGR < 16 can also be used for Human Centric Lighting (HCL) applications.

AQUALUC now available in 48 V DC

In addition, the AQUALUC series has been expanded. The fully encapsulated LED light lines offer countless possibilities in lighting design. They can be used in many areas indoors and outdoors as accent or direct lighting and offer a very high quality of light. With the new AQUALUC S:OLID 270°, Barthelme now offers even more scope for new lighting ideas. The new LED light line has three light emission surfaces and is equipped for a wide range of applications thanks to IP 68 protection. In addition, all AQUALUC LED light lines are now also available in 48 V versions. This allows several interconnected sections to be operated over a length of up to 22.95 m, depending on the version, with just one in-feed.

Linear lighting solution for concrete ceilings and walls

With the PALERMO BE recessed concrete profile, Barthelme offers the possibility of integrating linear light lines directly into exposed concrete ceilings and walls. The profile is used to accommodate project-specific linear luminaires from Barthelme, which are mounted in the profile with special magnetic holders after installation. The PALERMO BE modular system includes the basic profile, a 90° corner profile, a connecting piece, end piece and mounting accessories. The basic profile can be cut to the desired length. The connecting piece also makes it possible to join individual blanks of the basic profile together. We have developed the dimmable PALERMO and PALERMO T LED linear luminaires of the same name with an adjustable magnetic holding system to match.

In-feed lengths increased

The LEDlight flex Standard 2.0 LED strip series has been optimized and now features a double-layer FPC (flexible printed circuit) which results in a decisive advantage over the previous version. The upgrade reduces the voltage drop of the LED strip, thereby significantly increasing the feed-in lengths by over 40%. The performance data remains unchanged compared to the previous series.

Flexible LED strip for simple applications

With the new LEDlight flex LITE series we offer a LED strip for simple applications in private residential environments. Current regulation takes place via resistors. The LED strips achieve a luminous flux of up to 1,500 lumens, have good color rendering (typ. CRI 90) and are available in color temperatures of 2700 K, 3000 K and 4000 K.

Uniform illumination with Chip on Board technology

Also new in the range are the LED STRIP BASIC COB LED strips with Chip on Board technology. They have a continuous phosphor layer without visible, individual light points. This enables the realization of homogeneous light lines even in particularly flat LED profiles and in all LED profiles with clear diffusers. With 546 LED chips per meter, the LED strips of this series have a very high chip density. They are seamlessly dimmable without loss of efficiency and thanks to the very short pitch of only 38.5 mm, the COB LED strips offer great flexibility in luminaire construction.
