LEDLIGHT FLEX 10 8PF 5V

binned according to 2 Step MacAdam per light colour
available in six white tones, from 2,300 K to 5,500 K
tool-free connection possible with plug connectors
with 5 V DC operating voltage specially designed for USB and battery applications
very small cutting length of only 3 cm
LED chips with efficient heat management and good light yield
with reverse polarity diode
good heat dissipation due to high amount of copper in FPC and 3M thermoconducting adhesive tape
estimated lifetime L70 at Tc < 80 °C: > 60,300 h

Input voltage: 5 VDC
Channels: 1
Min. bend radius: 20 mm

Catalogue | Manuals

Products
Accessories

ANr*	Colour	Description	Colour temperature	Lumen	Power	Lumen/ watt	Lumen/ meter	CRI	Dimensions	Number LED	Watt/ meter
50000529	super warm white \| 823	Cut	2300 K	26 lm	0,3 W	85 lm/W	850 lm/m	83	30×8×1,4 mm (l×w×h)	3	10 W/m
50400529	super warm white \| 823	Reel	2300 K	2754 lm	32,4 W	85 lm/W	850 lm/m	83	3240×8×1,4 mm (l×w×h)	324	10 W/m
50000528	warm white \| 827	Cut	2700 K	26 lm	0,3 W	85 lm/W	850 lm/m	83	30×8×1,4 mm (l×w×h)	3	10 W/m
50400528	warm white \| 827	Reel	2700 K	2754 lm	32,4 W	85 lm/W	850 lm/m	83	3240×8×1,4 mm (l×w×h)	324	10 W/m
50000533	white \| 830	Cut	3000 K	26 lm	0,3 W	85 lm/W	850 lm/m	83	30×8×1,4 mm (l×w×h)	3	10 W/m
50400533	white \| 830	Reel	3000 K	2754 lm	32,4 W	85 lm/W	850 lm/m	83	3240×8×1,4 mm (l×w×h)	324	10 W/m
50000527	white \| 835	Cut	3500 K	26 lm	0,3 W	85 lm/W	850 lm/m	83	30×8×1,4 mm (l×w×h)	3	10 W/m
50400527	white \| 835	Reel	3500 K	2754 lm	32,4 W	85 lm/W	850 lm/m	83	3240×8×1,4 mm (l×w×h)	324	10 W/m
50000534	cold white \| 840	Cut	4000 K	26 lm	0,3 W	85 lm/W	850 lm/m	83	30×8×1,4 mm (l×w×h)	3	10 W/m
50400534	cold white \| 840	Reel	4000 K	2754 lm	32,4 W	85 lm/W	850 lm/m	83	3240×8×1,4 mm (l×w×h)	324	10 W/m
50000515	daylight \| 855	Cut	5000 K	26 lm	0,3 W	85 lm/W	850 lm/m	83	30×8×1,4 mm (l×w×h)	3	10 W/m
50400515	daylight \| 855	Reel	5500 K	2754 lm	32,4 W	85 lm/W	850 lm/m	83	3240×8×1,4 mm (l×w×h)	324	10 W/m

Please note: Insufficient cooling will damage the LEDs

Processing notes for LEDlight flex

ANr	Description	Input voltage	Application	Degree of protection	Housing/ colour
51991012	LED cable and confectioning, cable with AR connector 100 cm 2 pole - soldered to LEDlight flex				white
50070203	LED plug-in system, LED strip to strip connector, 8 mm, for tool-free connection of 2 and 4-pole strips, 1 piece	3-48 VDC	Indoor	IP20
50070204	LED plug-in system, LED strip to strip connector, 8 mm, 40 mm cable, for tool-free connection of 2 and 4-pole strips, 1 piece	3-48 VDC	Indoor	IP20
50070201	LED plug-in system, LED strip to power connector, 8 mm, 2-pole, 50 cm cable with free wire ends, for tool-free connection of the strip, 1 piece	3-48 VDC	Indoor	IP20
50070202	LED plug-in system, LED strip to power connector, 8 mm, 4-pole, 50 cm cable with free wire ends, for tool-free connection of the strip, 1 piece	3-48 VDC	Indoor	IP20
50990004	Cable (Indoors), 2-pole cable 1m, white, for indoor use, PVC, 2x 0.34mm?
50991004	Cable (Indoors), 2-pole cable 1m, black, for indoor use, PVC, 2x 0.34mm²
50990721	LED cable and confectioning, cable 2 pole, with tin plated free wire ends - soldered to LEDlight flex
50990007	LED cable and confectioning, one-sided skinning and tinning/soldering to LEDlight flex (additionally cable), 2-pole, boundless wire ends
50990722	LED cable and confectioning, cable 2 pole, with tin plated free wire ends - soldered to LEDlight flex
50990723	LED cable and confectioning, cable 2 pole, with tin plated free wire ends - soldered to LEDlight flex
50990221	LED cable and confectioning, two-sided skinning and tinning/soldering to LEDlight flex (additionally cable), 2-pole, boundless wire ends

50070203, 50070204, 50070201, 50070202: Detailled processing notes see datasheet

50070202: Processing notes for LEDlight flex

Maximum LED Strips length in relation to supply line length »
