LUNA
FURNITURE SPOTLIGHT

dimmable recessed spotlight
especially developed with very flat build design for installation in furniture
ideal for illuminating surfaces from close range (e.g. shelves or kitchen alcoves)
aluminium, anodised
estimated lifetime L70 at Tc < 70 °C: > 50,000 h

Catalogue

ANr*	Colour	Colour temperature	Lumen	Power	Lumen/ watt	CRI
62544227	warm white \| 827	2700 K	215 lm	2,3 W	93 lm/W	82
62544233	white \| 830	3000 K	215 lm	2,3 W	93 lm/W	82
62544226	cold white \| 840	4000 K	270 lm	2,3 W	117 lm/W	82
62544215	daylight \| 850	5000 K	290 lm	2,3 W	126 lm/W	82

The above mentioned lumen values are valid for operation with 700 mA

The above spot is only qualifi ed for installation in furniture in combination with a power supply device with MM symbol (e.g. 62519900).

ANr	Description	Datasheets
62513000	extension cable for luminaires, Extension cable, 3m
62519908	extension cable for luminaires, Extension cable, 5m
62517000	extension cable for luminaires, Extension cable, 7m
62517001	extension cable for luminaires, extension cable, 10 m
62519901	Cable glands, connecting clamps, LED distributors, 2 output distributor with 2 m cable and one short-circuit plug
62519902	Cable glands, connecting clamps, LED distributors, 4 output distributor with 1 m cable and 3 short-circuit plugs
